Cables for movement chainflex®

Failsafe cables for energy chains - with guarantee
The chainflex® cables are unharnessed cables for moving applications in energy chains or for robot applications, fail-safe with 36 months guarantee.
The chainflex® cables meet the requirements for EMC safety as well as the standards and guidelines such as UL, CSA, VDE, EAC, CTP, Interbus and Profibus. Various jacket materials are available. The product range includes everything from control cables, servo cables, motor cables and robot cables to bus cables, data cables, encoder cables and fibre optic cables. The chainflex® cables for energy chains work flawlessly over long periods even with many cycles, high speeds and accelerations as well as very extreme ambient conditions.

Products

Core Requirements
Cable structure
Requirements
Material
Electrical information

Number of products: 20

chainflex® control cable CF880
chainflex® control cable CF880
chainflex® control cable CF880

from 0.23 USD / ft

14 of 38 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF880
  • Requirements: For flexing applications
  • Outer jacket: PVC
  • Flame retardant
  • Silicone-free
  • Oil resistance: No oil resistance
  • chainflex® class: 3.1.1.1

For flexible stressing capacity, PVC outer jacket, flame-retardant

Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 11008 and 2464, 300 V, 80 °C UL/CSA<br>Style 11008 and 2464, 300 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01560 CTP<br>Certified to no. C-DE. PB49.B.00449 Lead free<br>Following 2011/65/EU (RoHS-II) CE<br>Following 2014/35/EU
chainflex® control cable CF881
chainflex® control cable CF881
chainflex® control cable CF881

from 0.50 USD / ft

14 of 38 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF881
  • Requirements: For flexing applications
  • Outer jacket: PVC
  • Overall shield
  • Flame retardant
  • Silicone-free
  • Oil resistance: No oil resistance
  • chainflex® class: 3.1.1.1

For flexible stressing capacity, PVC outer jacket, shielded, flame-retardant

Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 11008 and 2464, 300 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01560 CTP<br>Certified to no. C-DE. PB49.B.00449 Lead free<br>Following 2011/65/EU (RoHS-II) CE<br>Following 2014/35/EU
chainflex® control cable CF130.UL
chainflex® control cable CF130.UL
chainflex® control cable CF130.UL

from 0.29 USD / ft

24 of 57 articles ready for shipping in 24 h
chainflex® control cable CF130.UL
  • Requirements: For medium duty applications
  • Outer jacket: PVC
  • Flame retardant
  • Silicone-free
  • Oil resistance: No oil resistance
  • CFRIP®
  • chainflex® class: 4.4.1.2

For medium loads, PVC exterior jacket, flame-retardant

Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 10493 and 20200, 300 V, 60 °C UL/CSA<br>Style 10493 and 20200, 300 V, 60 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF130.15.07.UL, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF140.UL
chainflex® control cable CF140.UL
chainflex® control cable CF140.UL

from 0.86 USD / ft

8 of 34 articles ready for shipping in 24 h
chainflex® control cable CF140.UL
  • Requirements: For medium duty applications
  • Outer jacket: PVC
  • Overall shield
  • Flame retardant
  • Silicone-free
  • Oil resistance: No oil resistance
  • CFRIP®
  • chainflex® class: 4.4.1.1

For medium duty applications, PVC exterior jacket, shielded, flame-retardant

Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 10493 and 20200, 300 V, 60 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF130.15.07.UL, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF5
chainflex® control cable CF5
chainflex® control cable CF5

from 0.51 USD / ft

7 of 42 articles ready for shipping in 24 h
chainflex® control cable CF5
  • Requirements: For heavy duty applications
  • Outer jacket: PVC
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • Oil resistance: Oil resistant according to DIN EN 50363-4-1
  • CFRIP®
  • chainflex® class: 5.5.2.2

For heavy duty, PVC outer jacket, oil-resistant, flame-retardant

UV resistance<br>Medium Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 10492 and 2570, 600 V, 80 °C UL/CSA<br>Style 10492 and 2570, 600 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF130.15.07.UL, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF890
chainflex® control cable CF890
chainflex® control cable CF890

from 0.44 USD / ft

11 of 38 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF890
  • Requirements: For flexing applications
  • Outer jacket: iguPUR
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • Oil resistance: Oil resistant according to DIN EN 50363-10-2
  • chainflex® class: 3.1.3.1

For flexible stressing capacity, iguPUR outer jacket, oil-resistant, flame-retardant

UV resistance<br>Medium Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, FT-2 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 11008 and 20940, 600 V, 80 °C EAC<br>Certified to no. TC RU C-DE. ME77.B.01560 CTP<br>Certified to no. C-DE. PB49.B.00449 Lead free<br>Following 2011/65/EU (RoHS-II) CE<br>Following 2014/35/EU
chainflex® control cable CF6
chainflex® control cable CF6
chainflex® control cable CF6

from 1.63 USD / ft

3 of 33 articles ready for shipping in 24 h
chainflex® control cable CF6
  • Requirements: For heavy duty applications
  • Outer jacket: PVC
  • Overall shield
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • Oil resistance: Oil resistant according to DIN EN 50363-4-1
  • CFRIP®
  • chainflex® class: 5.5.2.1

For heavy-duty applications, PVC outer jacket, shielded, oil-resistant, flame-retardant

UV resistance<br>Medium Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 11113 and 2570, 600 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 2, material/cable tested by IPA according to ISO standard 14644-1. CE<br>Following 2014/35/EU
chainflex® control cable CF891
chainflex® control cable CF891
chainflex® control cable CF891

from 0.72 USD / ft

10 of 38 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF891
  • Requirements: For flexing applications
  • Outer jacket: iguPUR
  • Overall shield
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • Oil resistance: Oil resistant according to DIN EN 50363-10-2
  • chainflex® class: 3.1.3.1

For flexible stressing capacity, iguPUR outer jacket, oil-resistant, shielded, flame-retardant

UV resistance<br>Medium Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, FT-2 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 11008 and 20940, 600 V, 80 °C EAC<br>Certified to no. TC RU C-DE. ME77.B.01560 CTP<br>Certified to no. C-DE. PB49.B.00449 Lead free<br>Following 2011/65/EU (RoHS-II) CE<br>Following 2014/35/EU
chainflex® control cable CF77.UL.D
chainflex® control cable CF77.UL.D
chainflex® control cable CF77.UL.D

from 0.80 USD / ft

15 of 48 articles ready for shipping in 24 h
chainflex® control cable CF77.UL.D
  • Requirements: For twistable applications
  • Outer jacket: PUR
  • Coolant resistant
  • Notch-resistant
  • Hydrolysis and microbe-resistant
  • Flame retardant
  • Halogen-free
  • Silicone-free
  • UV-resistant
  • PVC-free
  • Oil resistance: Oil resistant according to DIN EN 50363-10-2
  • chainflex® class: 5.1.3.3

For heavy duty, PUR outer jacket, resistant to oil and coolant, cut-resistant, PVC-free and halogen-free, hydrolysis-resistant and microbe-resistant,

UV resistance<br>Medium Offshore<br>MUD-resistant following NEK 606 - status 2009 Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). Halogen-free<br>Following EN 50267-2-1 UL/CSA<br>Style 10493 and 20233, 300 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 DNV-GL<br>Certified according to DNV-GL Type Testing – Certificate No.: 61 935-14 HH EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF77.UL.05.12.D, tested by IPA according to standard 14644-1 DESINA<br>According to VDW, DESINA standardization CE<br>Following 2014/35/EU
chainflex® control cable CF78.UL
chainflex® control cable CF78.UL
chainflex® control cable CF78.UL

from 1.65 USD / ft

5 of 36 articles ready for shipping in 24 h
chainflex® control cable CF78.UL
  • Requirements: For heavy duty applications
  • Outer jacket: PUR
  • Overall shield
  • Coolant resistant
  • Notch-resistant
  • Hydrolysis and microbe-resistant
  • Flame retardant
  • Halogen-free
  • Silicone-free
  • UV-resistant
  • PVC-free
  • Oil resistance: Oil resistant according to DIN EN 50363-10-2
  • CFRIP®
  • chainflex® class: 5.5.3.1

For heavy duty, PUR outer jacket, shielded, resistant to oil and coolant, flame-retardant, notch-resistant, free of PVC and halogen, resistant to hydrolysis and microbes

UV resistance<br>Medium Offshore<br>MUD-resistant following NEK 606 - status 2009 Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). Halogen-free<br>Following EN 50267-2-1 UL/CSA<br>Style 11323 and 21223, 1.000 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 DNV-GL<br>Certified according to DNV-GL Type Testing – Certificate No.: 61 935-14 HH EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF77.UL.05.12.D, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF2
chainflex® control cable CF2
chainflex® control cable CF2

from 1.85 USD / ft

12 of 12 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF2
  • Requirements: For extremely heavy duty applications
  • Outer jacket: PUR
  • Overall shield
  • Coolant resistant
  • Notch-resistant
  • Hydrolysis and microbe-resistant
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • Oil resistance: Oil resistant according to DIN EN 50363-10-2
  • chainflex® class: 6.5.3.1

For extremely heavy duty, PUR outer jacket, shielded, resistant to oil and coolant, flame-retardant, notch-resistant, resistant to hydrolysis and microbes

UV resistance<br>High Offshore<br>MUD-resistant following NEK 606 - status 2009 Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 10493 and 20317, 300 V, 80 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF27.07.05.02.01.D, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF9
chainflex® control cable CF9
chainflex® control cable CF9

from 0.67 USD / ft

54 of 56 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF9
  • Requirements: For heaviest duty applications
  • Outer jacket: TPE
  • Coolant resistant
  • Low-temperature-flexible
  • Hydrolysis and microbe-resistant
  • Halogen-free
  • Silicone-free
  • UV-resistant
  • PVC-free
  • Oil resistance: Oil resistant according to DIN EN 60811-404, resistant to organc oils according to VDMA 24568 with Plantocut 8 S-MB by DEA
  • CFRIP®
  • chainflex® class: 7.6.4.2

For extremely heavy duty use, TPE outer jacket, resistant to oils / organic oils, free of PVC and halogen, cold-flexible, resistant to hydrolysis and microbes

UV resistance<br>High Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). Halogen-free<br>Following EN 60754 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 Lead free<br>Following 2011/65/EU (RoHS-II) Clean room<br>According to ISO Class 2, material/cable tested by IPA according to ISO standard 14644-1. CE<br>Following 2014/35/EU
chainflex® control cable CF9.UL
chainflex® control cable CF9.UL
chainflex® control cable CF9.UL

from 1.15 USD / ft

35 of 46 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF9.UL
  • Requirements: For extremely heavy duty applications
  • Outer jacket: TPE
  • Coolant resistant
  • Low-temperature-flexible
  • Hydrolysis and microbe-resistant
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • PVC-free
  • Oil resistance: Oil resistant according to DIN EN 60811-404, resistant to organc oils according to VDMA 24568 with Plantocut 8 S-MB by DEA
  • CFRIP®
  • chainflex® class: 6.6.4.2

For very heavy duty use, TPE outer jacket, resistant to oils / organic oils, flame-retardant, free of PVC, cold-flexible, resistant to hydrolysis and microbes

UV resistance<br>High Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 10479 and 21529, 300 V, 90 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 DNV-GL<br>Certified according to DNV-GL Type Testing – Certificate No.: 61 935-14 HH EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF34.UL.25.04.D, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF10
chainflex® control cable CF10
chainflex® control cable CF10

from 1.95 USD / ft

40 of 40 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF10
  • Requirements: For heaviest duty applications
  • Outer jacket: TPE
  • Overall shield
  • Coolant resistant
  • Low-temperature-flexible
  • Hydrolysis and microbe-resistant
  • Halogen-free
  • Silicone-free
  • UV-resistant
  • PVC-free
  • Oil resistance: Oil resistant according to DIN EN 60811-404, resistant to organc oils according to VDMA 24568 with Plantocut 8 S-MB by DEA
  • CFRIP®
  • chainflex® class: 7.6.4.1

For extremely heavy duty use, TPE outer jacket, shielded, resistant to oils / organic oils, free of PVC and halogen, cold-flexible, resistant to hydrolysis and microbes

UV resistance<br>High Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). Halogen-free<br>Following EN 60754 EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 Lead free<br>Following 2011/65/EU (RoHS-II) Clean room<br>According to ISO Class 1. Outer jacket material complies with CF9.15.07, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU
chainflex® control cable CF10.UL
chainflex® control cable CF10.UL
chainflex® control cable CF10.UL

from 2.52 USD / ft

26 of 32 articles ready for shipping in 1 - 2 weeks
chainflex® control cable CF10.UL
  • Requirements: For extremely heavy duty applications
  • Outer jacket: TPE
  • Overall shield
  • Coolant resistant
  • Low-temperature-flexible
  • Hydrolysis and microbe-resistant
  • Flame retardant
  • Silicone-free
  • UV-resistant
  • PVC-free
  • Oil resistance: Oil resistant according to DIN EN 60811-404, resistant to organc oils according to VDMA 24568 with Plantocut 8 S-MB by DEA
  • CFRIP®
  • chainflex® class: 6.6.4.1

For very heavy duty use, TPE outer jacket, shielded, resistant to oils / organic oils, flame-retardant, free of PVC, cold-flexible, resistant to hydrolysis and microbes

UV resistance<br>High Flame retardant<br>According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1 Silicone-free<br>Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992). UL/CSA<br>Style 10479 and 21529, 300 V, 90 °C NFPA<br>Following NFPA 79-2012 chapter 12.9 DNV-GL<br>Certified according to DNV-GL Type Testing – Certificate No.: 61 935-14 HH EAC<br>Certified to no. TC RU C-DE. ME77.B.01254 CTP<br>Certified to no. C-DE. PB49.B.00416 Lead free<br>Following 2011/65/EU (RoHS-II) CEI<br>Following CEI 20-35 Clean room<br>According to ISO Class 1. Outer jacket material complies with CF34.UL.25.04.D, tested by IPA according to standard 14644-1 CE<br>Following 2014/35/EU

Not-yet-assembled cables

As experts in everything to do with e-chains®, we know how important cables in energy chains are. Especially where continuous movement under extreme conditions is concerned. Standard cables in moving applications give up the ghost relatively quickly and this is why we developed the chainflex® product line. chainflex® cables are specially designed for use in "motion". This means that they last for many million cycles in moving applications. As an e-chain® can hold cables other than servo cables, our range of products include many other types of cable such as data cables and bus cables. chainflex® cables are flame-retardant and oil-resistant and are therefore able to cope with the most difficult conditions of use. More chainflex® cables:

Do you have any questions about igus® chainflex® cables?
We are always there to help you!
Questions regarding this topic:
chainflex® servo cables can be supplied with a PVC or PUR jacket and have a bend radius starting at 7.5 x d. They reach a speed of up to 10 m/s. Due to the special structure of the chainflex® cables, millions of cycles in e-chains® are not a problem. Moreover, the long service life and the weight enable low-maintenance designs in extremely different areas of use. For production lines where only simple maintenance measures are possible, for example, or on ships in extreme weather. With chainflex® cables, you are always well prepared.
